NameStefan Stammler
5. Oktober 2017

Application Deployment with Ansible

The Problem

Our developers work hard every day to improve thomann.de. They implement cool new features and hunt down nasty bugs (sometimes they even do both at the same time by implementing cool new bugs). However, to see the fruits of their work, the code they produce somehow needs to get to the web servers driving our site. When the new code has been tested and approved for release, the actual deployment process needs to be easy to initiate and fail safe in execution, so that the responsible release manager can trigger it without assistance from DevOps or System Administration.

The Requirements

There are a couple of requirements our deploy system needs to meet.

Simultaneous activation

When you access a page on www.thomann.de, the load balancers assign your page request to an arbitrary server from our production web server pool. So whenever you reload the page your browser is showing, chances are high that a different server will deliver the page.

Imagine we would change the background color from black to pink in our code. Then we start rolling out the change to our webservers, but it takes several minutes for one server to be deployed. The effect would be that with each click on thomann.de you would get either a black or a pink page, depending on whether the server you have been directed to has already been deployed or not.

To avoid that effect, it is important that new code is activated nearly simultanously on all servers.

Easy Rollback

Sometimes it is necessary to roll back a change, e.g. when errors occur that did not come up during development or staging tests. Such a rollback needs to be fast, and revert the production systems to a consistent state (ideally to the state before the faulty deployment).

Automated Service Reload

After the new version of the software has been distributed, certain components (e.g. the web server) on the production servers need to be triggered for reloads and cache refreshes to activate the changes. Usually, this requires privileged actions on each server, e.g. stopping and restarting a service. Thus, the central deployment system must be able to trigger those actions remotely. To achieve a nearly simultanous activation, the actions should be triggered parallely.

Abort Threshold

There are things that can go wrong during the deployment process. For example, the web server restart might fail. If that problem occurs on all servers, the website would be down after the deployment run. To avoid this, the rollout should abort if a certain number of servers failed, so that enough servers are left to run the website.

Implementation with Ansible

Ansible is an open source software that had been developed to perform automated software provisioning, configuration management and application deployment. In a typical deployment setup, there is a master server (”control machine”) and multiple slaves (”nodes”). The actual control process is running on the master. During its execution, it can run processes on the slaves, transfer files or run processes on the master itself.

To get access to the slaves, the master just needs an ssh account on the target machine. Authentication is usually done with SSH keys. The advantage of SSH is that Ansible can run any command on the slaves, just as if a user was logged in. The account’s privileges can be fine tuned so that only privileges that are required for the intended usage are granted.

Distributing the Application

To have a consistent application state, we first collect all files that need to be deployed - application files, templates, resource files etc. - and put them together into a bundle. This bundle is just a simple .tar.gz file.

This bundle now needs to be distributed to the production servers. This is the first task where Ansible can take over. On the Ansible master, a control process is started that executed a playbook.

Playbooks are written in YAML, as are most Ansible configuration files. Each playbook consists of a list of tasks and operates on a selection of hosts (i.e. the slaves). Each task calls a module that is executed on each of the hosts.

Typical tasks are:

  • copy a file from the master to the slave
  • copy/move files or directories between locations on the slave
  • extract an archive file
  • create or delete a file/directory
  • change the permissions or ownership of a file/directory
  • send mails or notifications

Ansible provides a large amount of built-in modules, and even allows to write own modules. There are already modules for most of the standard Unix commands.

This is how a simplified version of our deployment distribution playbook looks like:

- hosts: production
  - vars-common.yaml

  strategy: free

    - name: copy bundle to remote host
      copy: src={{ filepath_master_bundle }} dest={{ filepath_remote_bundle }}
    - name: create remote bundle directory
      file: path={{ path_remote_bundles }} state=directory mode=0775
    - name: extract bundle to target directory
      unarchive: copy=no src={{ filepath_remote_bundle }} dest={{ path_remote_bundles }}

The first line just defines which host list is used for this playbook run. In this case, we want to distribute our bundle to all production hosts. The list itself is defined in a global inventory file on the master.

With the next lines, some variable definitions from a separate file (vars-common.yaml) are imported. Variables are a great method to hold definitions like file names etc. at a central place, so that they can be used from multiple playbooks.

The strategy defines the order and parallelity Ansible uses when executing the tasks. While tasks are executed in strict order on each individual host, this is not necessarily true for the hosts. With the free strategy we are using here, Ansible can decide on its own how many hosts are run parallely, and when tasks are actually executed. It might even happen that the first couple of hosts have already finished, while some hosts have not even yet started.

At the end, the tasks are defined. First we copy the bundle with the version from the master to the slave. With the file module, we ensure that the target directory (where we intend to extract the bundle to) exists and has the proper permissions. Finally, we unarchive the bundle to the target directory (tar extract).

When the Ansible playbook run on the master has finished, all slaves have a new directory with the contents of the bundle we want to deploy. The slaves are now ready to switch to the new version.

Activating the New Version

To activate the new version, another playbook is executed. This playbook follows a different strategy. On one hand, we want the change to roll out nearly simultanously. On the other hand, if something goes wrong during activation, or the new version does not run properly, we want to have enough production machines running the old version in case we need to abort the activation.

Again, here is a simplified version of the playbook for the activation:

- hosts: production
  - vars-common.yaml

  strategy: linear
  serial: "33%"
  max_fail_percentage: 33

    - name: run initial smoke test to make sure everything is OK
      script: "{{ web_smoke_test_command }} {{ inventory_hostname }}"
    - name: web server config test
      shell: "{{ web_server_test_config_command }}"
    - name: link production directory to new bundle directory
      file: src={{ path_remote_bundle }} dest={{ path_remote_prod }} state=link }}"
    - name: web server graceful reload
      shell: "{{ web_server_graceful_command }} warn=no"
    - name: run smoke test to make sure the new version is running
      script: "{{ web_smoke_test_command }} {{ inventory_hostname }}"

The linear strategy will execute the tasks on batches of hosts parallely. In this case, we chose a batch size of 33%. The next batch will start only after the previous batch has finished. Additionally, we specify a maximum fail percentage of 33%. That means, if at least 33% of the hosts failed to run the tasks without error, the execution will stop and the remaining hosts are skipped. So if the first batch fails, further activation of the new version is stopped, and the remaining 66% can still deliver the previous version.

The actual activation tasks first do a smoke test to ensure the application is in a proper state before we begin. Then we verify the web server configuration to avoid that we restart the server with an invalid configuration. Then we point the production application directory to the bundle path where we extracted the files in the distribution playbook run by setting a softlink with the file module. After the reload of the web server, a final smoke test ensures the application is still running properly with the new version.


In case we need to roll back to a previous version, we just need to run the activation playbook and pass the bundle directory of that version in the path_remote_bundle variable. As we keep older bundles on the production servers for some time, the distribution playbook (which takes much more time than the activation playbook) is obsolete.


Ansible is a great tool for automating jobs like software deployment. There are hundreds of module available, and many more features like conditionals, loops etc. that were not covered in this article. If you are interested, check out the official documentation.

Have fun!
